80A MPPT Solar Charge Controller, 12V 24V 48V auto recognition, top quality

  • 1 - 9 Units
    $130.00
  • 10 - 19 Units
    $125.00
  • >=20 Units
    $120.00
Rated Voltage:
48V
Maximum Current:
80A
Lead Time:
Quantity(Units) 1 - 100 >100
Est. Time(days) 7 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
SAKO
Model Number:
SC-M 80A
Application:
Charger Controller, Solar System Controller, Solar system and Street light system
Work Time (h):
24H
Max PV Voltage:
165Vdc
Max PV Power:
4800w
Charge Type:
MPPT
Max. charge current:
80A
Protection functions:
Overload, over voltage, low voltage, Reverse connection, etc
Display:
LCD
Supply Ability
Supply Ability:
50000 Unit/Units per Month
Packaging & Delivery
Packaging Details
Standard international paper box packing.
Port
Shenzhen
Picture Example:
package-img
package-img
Lead Time :
Quantity(Units) 1 - 100 >100
Est. Time(days) 7 To be negotiated

Main Features of SC-M series MPPT solar charge controller

1.Automatic Identification System Voltage,12V 24V 48V auto recognition and ataptive.

2. MPPT tracking way, max charging efficieny up to 99%, 15%-20% higher than PWM mode In charging efficiency,Save 20% Solar Panel

3. Wide PV input range,and the max PV input votlage reaches to 150Vdc.

3.Humanized LCD displaying and double button operation of man-machine interface.

4.Completed technical data for setup and modify.

5. Intelligent design, can be upgraded online

6.Reliable over voltage,short circuit,over load,overcharge,over-discharge protection

7. High degree power Save function, nght consumption <1W

8.Roundly reverse connected protection.

9.Temperature Compensation Function



Product Show



1713_02










1713_04

MODELSC-M-20ASC-M-30ASC-M-40ASC-M-50ASC-M-60ASC-M-80A
SPECIFICATION
                                                                      P.V. Input Features
Input P.V. Range(Vdc)≤150VDC
Solar Charge Current(A)20A Max.30A Max.40A Max.50A Max.60A Max.80A Max.
                                                                      Solar Charging Features
Normal Battery Voltage(Vdc)12/24/48VDC
Battery Type ChooseGel/Sealed/other(User-defined)
Fast Charge Voltage(Vdc)14.0V ; X2/24V ; X4/48V  other(User-defined)
Folat Charge Voltage(Vdc)13.8V ; X2/24V ; X4/48V  other(User-defined)
Overcharge Alarm Voltage(Vdc)15.0V ; X2/24V ; X4/48V  other(User-defined)
Overcharge Protection Voltage(Vdc)15.0V ; X2/24V ; X4/48V  other(User-defined)
Overcharge Recovery Voltage(Vdc)13.6V ; X2/24V ; X4/48V  other(User-defined)
                                                                      DC Output Features
DC Output Current(A)20A Max.30A Max.40A Max.50A Max.60A Max.80A Max.
Overdischarge Alarm Voltage(Vdc)11.0V ; X2/24V ; X4/48V  other(User-defined)
Overdischarge Protection Voltage(Vdc)10.5V ; X2/24V ; X4/48V  other(User-defined)
Overdischarge Recovery Voltage(Vdc)14.0V ; X2/24V ; X4/48V  other(User-defined)
                                                                PROTECTION
ProtectionOvercharge protection,Overdischarge protection,Solar reverse polarity protection,Overtemperature protection
                                                                Display Features
Display methodLED+LCD
Display subtancePV status,Battery status,DC Output status,fault status
                                                         AMBIENT
Noise(dB)< 55dB (1 meter)
working Temperature -20℃~50℃
Humidity0~95% ( no condensation)
Sea Level(m)≤1500
                                                            DIMENSION
L×W×H (products size) mmL205*W167*H93.5mmL260*W223*H93.5mm
L×W×H (package size) mmL640*W565*H305mmL640*W565*H305mm
Weight(NW Kg)2.1Kg3.0Kg
Packge Weight(GW Kg)21Kg15Kg
