The Newest 3.2KW Hybrid Mppt Solar Inverter, Supports No Battery Working And WIFI Remote Control

  • 50 - 99 Pieces
    $320.00
  • 100 - 199 Pieces
    $300.00
  • >=200 Pieces
    $280.00
Application:
Off-Grid Solar System Hybrid Solar System
Output Power:
3000w
Lead Time:
Quantity(Pieces) 1 - 500 >500
Est. Time(days) 45 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
SAKO
Model Number:
SUNPOLO 3.2KW
Output Type:
Single
Input Voltage:
24VDC (Battery)
Output Voltage:
220Vac or 230Vac
Type:
DC/AC Inverters
Output Frequency:
50Hz/60Hz
Output Current:
15A
Size:
303X471X146mm
Weight:
9KGS
Price:
Competitive
PV Input:
4000W (250W*16PCS)
Norminal Pv Voltage:
240Vdc
Max.Charging Current ( AC+Solar):
80Amp
Supply Ability
Supply Ability:
8000 Piece/Pieces per Month Solar Inverter
Packaging & Delivery
Packaging Details
Standard international paper box packing.
Port
Shenzhen
Picture Example:
package-img
package-img
Lead Time :
Quantity(Pieces) 1 - 500 >500
Est. Time(days) 45 To be negotiated

SUNPOLO 3KW  Off Grid Mppt Solar Inverter, Supports No Battery Working And WIFI Remote Control



Features

1. With MPPT solar charger controller built inside. 2. Wide PV input range (Up to 600Vdc), can work without battery during the day time. 3. Various communication such as WIFI/RS485/RS232 optional. 4. Smart and intelligent pure sine wave, high frequency technology,wall amounted design,light weighted and easy to operate
5. Selectable charging current based on applications
6. Configurable AC/Solar input priority via LCD setting
7. Compitable with (LI Ion, LiFePo4 and ect.), batteries with BMS system and battery equalization 8. Parallel operation with up to 9 units for 5KW
9. Auto restart while AC is recovering, auto charge and switch, unattended operation 10. Smart battery charger and management for optimized battery performance
12. High Efficient DC-To-AC Conversion.Minimizing Energy Loss and self power consumption 13. All around protection functions: Overload/short circuit protection/high voltage/low battery voltage/high temerature,etc.





Specification

SUNPOLO Smart pure sine wave Solar inverter +MPPT solar charger+AC charger inside, high frequency technology, 100% power, Configurable AC/Solar input priority via LCD setting.Wall mounted design. AC Output: 230V. Support wifi and computer monitor withRS232 interface.Max PV input: 500Vdc.  Can work without battery at daytime.



Product Description
Rated PowerSUNPOLO 3.2KWSUNPOLO 5.2KW
INPUT
Voltage230VAC
Voltage Range176-280 VAC at 100% load
110-280 VAC at 50% load
Frequency Range50Hz/60Hz(Auto sensing)
OUTPUT
AC Voltage Regulation(Batt.Mode)230VAC±3%
Surge Power6400VA for 5 sec10400VA for 5 sec
Efficiency(Peak)>95% ( Rated R load, battery full charged
Transfer Time10ms typical (UPS)
20ms typical (Appliances)
WaveformPure sine wave
BATTERY
Battery Voltage24 VDC48 VDC
Floating Charge Voltage27 VDC54 VDC
Overcharge Protection32 VDC64 VDC
SOLAR CHARGER & AC CHARGER
Solar Charger TypeMPPT
Maximum PV Array Open Circuit Voltage500VDC
Maximum PV Array Power4000W5000W
MPP Range@ Operating Voltage120-450VDC120-450VDC
Maxmum Solar Charge Current80A80A
Maximum AC Charge Current60A
PHYSICAL
Dimension,D X W X H (mm)303*471*146/530*377*217
Net Weight(kgs)11.512.2
Communication InterfaceRemovable OTG USB/RS232/RS458/BLE/Dry-contact,BMS interface,
OPERATING ENVIRONMENT
Humidity5% to 95% Relative Humidity(Non-condensing)
Operating Temperature-10℃ to 50℃
Storage Temperature-15℃ to 60℃
*Product specifications are subject to change without further notice








new products

other Products

Company Information







Certifications



Packaging & Shipping



FAQ


FAQ


Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.

Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.

Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.

Q4: What is the warranty of inverter?
A4: One year warranty on Solar product.

Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
